High performance freehub for disc brakes: XT is renowned for offering the best performance to value ratio.

Technology

Centre Lock

The Centre Lock system makes an easy rotor installation possible with spline mount and a lock ring. The lock ring mounting system reduces the total working hours by shortening the amount of time of both installation and de-installation. In addition, the secure fixing by the spline mount enhances precision and rigidity while improving braking efficiency.

Quick Engagement

Shimano’s rear road wheels and hubs are equipped with 18/16 notches for quick engagement. In contrast to road racing, MTB XC tracks have many sharp turns and steep hills, where quick engagement is essential. Shimano has improved the rear hubs of its high end MTB group sets and wheels and equipped them with 18/16 notches and two sets of pawls to double the engagement and optimize traction.

MicroSpline

MicroSpline delivers lightweight aluminum freehub body to reduce weight and 10 teeth top gear. Use combination with MicroSpline cassette and freehub.

Benefits and features:

• Lightweight aluminum MicroSpline freehub seamlessly integrates with small 10-tooth top gears
• Smaller and more widely distributed splines limit cog damage on lightweight aluminum freehub

Features

• MicroSpline freehub has be developed to enable the use of a 10T cassette sprocket, to be used in conjunction with Shimano 12-speed cassettes
• MicroSpline freehub body with quick pawl engagement (10 degrees) provides perfect traction and instant power transfer
• Designed for use with Centre Lock disc rotors for secure hassle free set-up
• Double contact sealing with internal grease sleeve helps to keeps out water and dirt from bearings ensuring constant smoothness and longevity whilst keeping the grease in place
• Borozon treated cone bearing races provide precision low-friction rolling
• Cup and cone bearings for durability, strength and smooth rotation
• For 12 x 142mm and 12 x 148mm boost dropouts (axle not included)
