GRAPHENpads® - the new era of braking confidence and consistency is here

Ceramic GRAPHENpads® are a completely new benchmark for the braking pad industry thanks to their unique approach to the design of backplate cooling fins, bespoke backplate coating with graphene as well as a completely new friction compound, which uses specially modified graphene instead of toxic copper. These pads fit Shimano road calipers like Dura-Ace, Ultegra, 105 and more.

Features

• First pads on the market containing specially modified graphene in their friction compound, which greatly improves braking performance, durability and heat transfer to the backplate.
• Thanks to the backplates being entirely covered in graphene heat dissipating coating, it was possible to achieve much greater heat transfer from the friction material to the cooling fins and at the same time, increase radiation of heat (IR spectrum) by over 20% (which is very significant).
• First pads in the market with patented, angled radiator fins for superior airflow and cooling. Angle cutting provides three major benefits. 1- increased overall surface of the radiator by 40% vs standard cutting methods. 2- significantly greater airflow compared to traditional radiators that increases convective heat dissipation 3 –most importantly, 45deg angle cutting makes all the surfaces radiate the heat away from the brake pad. Heat radiation (IR spectrum) is the highest in perpendicular direction to the surface so in a standard radiator, every fin is radiating its heat at a neighboring fin, keeping more heat in the element. Their pads radiate all the heat away from the back plate.
• To date, GRAPHENpads® are the only brake pads in the market that completely eliminate toxic copper, ahead of new regulations (copper brake dust is proven to be toxic to aquatic life hence new California regulation will ban use of copper from 2025)
• In the box: Two pads, one spring.

Technical specifications

• Compatibility: Shimano Dura Ace BR-R9270,BR-R9170, Ultegra BR-R8170,BR-R8070, 105 BR-R7070, Tiagra BR-4770, GRX BR-RX810,BR-RX400, XTR BR-M9100,BR-M9110, XT BR-M8110, SLX BR
• M7110, Metrea BR-U5000, BR-RS805, BR-RS505, BR-RS405, BR-RS305, TRP HD-T910, Tektro HD-R510, HD-R310, Rever MCX1 Flat Mount.
• Composition: Ceramic organic Performance friction compound containing graphene. Thermal coating containing graphene. They don't use copper or any heavy metals.
• Usage: All weather conditions.
• Lifespan: AbsoluteBlack declare that a single set of pads lasted on average 8000km ( 4900 mi) in hilly terrain.
